A Smart SDR with MEMS and GPS

NVX-ORC-A6x combines advanced wideband RF processing capabilities with integrated GPS/GLONASS and a 10-axis MEMS positioning sensor — all packed into a compact M.2 form factor with broad out-of-the-box compatibility across modern platforms.

Early Access

Overview

The NVX-ORC-A6x is a highly integrated and compatible radio module that combines modern wideband radio processing capabilities based on a AMD Artix-7 FPGA with a high-frequency RFIC transceiver (AD936x) from Analog Devices. Its compact size, high compatibility, and performance radically simplify product development, making the NVX-ORC-A6x an ideal choice wherever small dimensions, rich functionality, and high performance are required. In an M.2 form factor, the NVX-ORC-A6x can be used in millions of host devices that support PCIe-based SSDs.


Applications

  • Mobile Device Detection
    NVX-ORC-A6x helps various industries protect their staff, infrastructure, and customers by using a modern approach to detecting mobile phones and other radio devices.
  • RF Spectrum Analysis
    NVX-ORC-A6x is a modern spectrum analysis solution that is easy to use and can be integrated into commercial laptops or tablets. Visualize and record RF signals in ready-made or custom-built products.
  • Network Configuration Survey
    NVX-ORC-A6x is a scanning receiver that helps you better understand the wireless networks around you.
  • Prototype Wireless
    NVX-ORC-A6x is an SDR platform designed for rapid prototyping of wireless solutions with advanced capabilities.
Specification
More details and links coming soon — in development.
RF INTERFACE
  • Antenna Port 1: U.FL coaxial connector supporting Rx
  • Antenna Port 2: U.FL coaxial connector supporting either Tx or Rx
RF TUNING RANGE
  • 70 MHz to 6 GHz (for AD9361)
RF CHANNEL BANDWIDTH
  • Up to 50 MHz (for AD9361)
TYPICAL RX NOISE FIGURE
  • < 8 dB
TYPICAL RX IIP3
  • -10 dBm
RX AND TX SAMPLE RATES RANGE
  • 233 Ksamples/sec to 61.44 Msamples/sec
A/D AND D/A CONVERTER SAMPLE WIDTH
  • 12-bits
RX GAIN RANGE
  • 0-76 dB, 1 dB steps
TX GAIN RANGE
  • 0-89 dB, 0.5 dB steps
TYPICAL TX OUTPUT POWER
  • +10 dBm (+13 dBm < 2 GHz)
GPS
  • NMEA sentences and frequency-disciplining Multi-channel GPS and GLONASS/BEIDOU, SBAS, QZSS overlay systems receiver U.FL antenna input, 3.3V bias for active GPS antenna.
EXTERNAL CLOCK REFERENCE
  • W.FL coaxial input, configurable for 10 MHz or 40 MHz input clock W.FL coaxial output, 40 MHz signal suitable to drive another Sidekiq module
FPGA
Xilinx Artix 7 XC7A75T FPGA with x4 Gen2 PCIe interface to host
FPGA REPROGRAMMING
Over PCIe (supports partial reconfiguration as well as reprogramming of FPGA boot flash)
GPIO
Available at M.2 edge connector; one GPIO available on a W.FL connector
COMPONENT TEMPERATURE RANGE
-40 deg C to +85 deg C
TEMPERATURE SENSOR
-55 deg C to +125 deg C (+/- 2 deg C)
MOTION TRACKING
6-axis, combining a 3-axis gyroscope and 3-axis accelerometer
FORM FACTOR
M.2 2280 key M form factor
DIMENSIONS
22mm x 80mm x 4.5mm
WEIGHT
9.07g
TYPICAL POWER CONSUMPTION
2.5W

Development Tools
FPGA development
  • BIST - Built-In Self-Test for Linux / Win
Application development
  • AMD Tools - Vivado Design Suite HLx Editions: HDL and C/C++ with HLS
PCIe carrier card
  • PCIe carrier card allowing NVX-ORC-A6x to be populated in a standard PCIe slot for lab development
Deliverables
  • NVX-ORC-A6x FPGA board
  • Built-In Self-Test (BIST)
  • Оptional expansion boards
  • JTAG cable
About me
Kostya Tiutin
Founder & Developer NVX-ORC
I am an engineer with 17 years of experience in the field of radioelectronic industry.

I believe! SDR computing should be available to everyone and be a friend to the green world.

SDR opens a gateway into an entirely different world — a world of other colors, invisible to the human eye, yet always present around us.

Together, we can build something greater than just a radio transmission system — we can deeply integrate this technology into our everyday lives, bringing about a true revolution in communication systems.
